Atomos ATOMSUMO19 Sumo19 19" HDR/High Brightness Monitor Recorder
MPN # ATOMSUMO19
UPC # 814164020817
Availability: In Stock
Condition: New
Product highlights:
  • Maximum Resolution: 1920 x 1200
  • Brightness: 1200 Nit - Maximum
  • Product Type: LCD Touchscreen Monitor
  • Condition: New
$2,095.00
B2B Pricing options available. Get Better Pricing.
Need Help?   let's talk about it.

Record ProRes RAW

Unlock the true potential of your RAW cinema camera with the Sumo19. Preserve your sensor's pristine pixels in ProRes RAW at up to 5.7kp30, 4kp120 DCI/UHD and 2kp240 DCI/HD. CDNG supports up to 4kp30 DCI. Sumo19 is compatible with Sony FS series, Canon C300MKII/C500 or Panasonic EVA-1/Varicam LT. Record up to 4kp30 in CDNG.

HDR in the field and in the studio

HDR really comes to life on the Sumo19. It's 19" 1920 x 1080 LCD panel with 10-bit processing takes the RAW/Log/PQ/HLG output from cameras or games consoles and precisely maps to display 10+ stops of dynamic range in real time. Use as a director or client monitor in the field, or an affordable HDR studio monitor.

10-bit ProRes/DNxHR up to 4Kp60

Video from any camera or digital video source can be captured via SDI or HDMI. Record up to 10-bit 4:2:2 in ProRes or DNxHR codecs at 4Kp60 or 2Kp240, depending on the camera's capability. The depth and quality of the image is preserved with data rates of up to 1.8Gbs, 220MB/s.

Live quad channel HD switching and recording

Live switch four 1080p channels and record each as separate ISOs. Switch between feeds intuitively on-screen with hard cuts. Save space by replacing several boxes in your rack with a single Sumo19.

Two stereo balanced XLR inputs with 48V

Use full size XLR connections with 48V Phantom power to connect two external microphones with balanced analogue audio recording and monitoring. The Sumo19 has dedicated meters, gain controls and adjustments for frame delay on each channel. Mic or line level audio can be seamlessly synchronized with embedded audio from HDMI and SDI sources.

Quad SDI & HDMI 2.0 In/Out

Seamlessly connect any SDI or HDMI device for monitoring and recording. Cross convert between HDMI 2.0 and 1.5G/3G/6G/12G/Quadlink & Dual link 12G SDI in almost any combination and eliminate the need for specialist converters.

General Information
Manufacturer
Atomos
Manufacturer Part Number
ATOMSUMO19
Manufacturer Website Address
http://www.atomos.com
Brand Name
Atomos
Product Line
Sumo
Product Model
19
Product Name
Sumo 19 Touchcreen LCD Monitor
Product Type
LCD Touchscreen Monitor
Technical Information
Screen Size Class
19"
Viewable Screen Size
19"
Screen Mode
WUXGA
Aspect Ratio
16:9
Mount Type
Rear Mount
Video
Maximum Resolution
1920 x 1200
Brightness
1200 Nit - Maximum
Audio
Speakers
Yes
Interfaces/Ports
HDMI
Yes
Number of HDMI Inputs
1
Power Description
Operating Power Consumption
75 W
Physical Characteristics
VESA Mount Compatible
Yes
Height
12.2"
Width
19.8"
Depth
2.5"
Height with Stand
12.99"
Width with Stand
19.84"
Depth with Stand
7.09"
Weight (Approximate)
12.02 lb
Weight with Stand (Approximate)
13.23 lb
Miscellaneous
Package Contents
  • Sumo 19 Touchcreen LCD Monitor
  • 1 x Master Caddy II
  • 1 x BattWing mounting bracket
  • 4 x Screws
  • 2 x Desktop Feet with 4x 1/4" Mounting screws
  • AC power supply
Warranty
Limited Warranty
1 Year
