SabreEDGE 4U HGX B300 DLC Server - ES4-10741069

Please log in to add an item to your wishlist. MPN: ES4-10741069

SabreEDGE 4U HGX B300 DLC Server - ES4-10741069

Highlights

Overview

Specifications

The SabreEDGE ES4-10741069 is based on the Intel Xeon 6500P/6700E/6700P Series. It features twelve 2.5" NVMe hot-swap drives and eight NVIDIA B300 SXM GPUs.

Specifications

Processor & Chipset

Number of Processors Supported

Processor Socket

Socket E2 LGA-4710

Processor Type

Xeon 6

Processor Supported

6500P-Series
6700E-Series
6700P-Series

Thermal Design Power (TDP)

350W

GPU

8x NVIDIA B300 SXM

Memory

Memory Technology

DDR5 SDRAM

Memory Standard

DDR5-6400/PC5-51200 RDIMM
DDR5-8000/PC5-64000 MRDIMM (1DPC population, Xeon 6500P/6700P-Series only

Number of Total Memory Slots

Controllers

NVMe

Via SoC

Display & Graphics

Graphics Controller Manufacturer

ASPEED

Graphics Controller Model

AST2600 BMC

Network & Communication

Ethernet Technology

1000BASE-T
800G OSFP

I/O Expansions

PCI Express

2x PCI-E 5.0 x16 FHHL slots
1x PCI-E 5.0 x2 M.2 slot (2280/22110)

Drive Bays

Hot-swap

12x 2.5" hot-swap drive bays
Supports PCI-E 5.0 x4 NVMe

Interfaces/Ports

USB Ports

4x USB 3.2 Gen1 (Front, Type A)
2x USB 3.2 Gen1 (Rear, Type A)

Number of NVMe Interfaces

12x U.2
1x M.2

LAN

1000BASE-T (Front/Rear shared)
1x RJ45 Dedicated Management Port (Front/Rear shared)
8x 800G OSFP (Front)

Onboard Video

1x VGA (Front)

TPM

1x TPM Header

Power Description

Number of Power Supplies

Redundant Power Supplies

Yes (5+5)

Maximum Power Supply Wattage

3002.4W

Certification

80 Plus Titanium

Physical Characteristics

Color

Black

Form Factor

Rack-mountable

Rack Height

Height

6.9"

Width

36.2"

Depth

17.1"
