SabreEDGE 1U Server - ES1-8038710

Please log in to add an item to your wishlist. MPN: ES1-8038710

SabreEDGE 1U Server - ES1-8038710

Highlights

Overview

Specifications

The SabreEDGE ES1-8038710 is based on the AMD EPYC 9004/9005 Series. It offers up to twelve 2.5" hot-swap drive bays and support for two PCI-E 5.0 x16 cards.

Specifications

Processor & Chipset

Number of Processors Supported

Processor Socket

Socket SP5 LGA-6096

Processor Type

EPYC

Processor Supported

9004-Series
9005-Series

Thermal Design Power (TDP)

360W

Memory

Maximum Memory

6 TB

Memory Technology

DDR5 SDRAM

Memory Standard

DDR5-4800/PC5-38400 (EPYC 9004 Series)
DDR5-6000/PC5-48000 (EPYC 9005 Series)

Number of Total Memory Slots

Controllers

Controller Type

NVMe

Display & Graphics

Graphics Controller Manufacturer

ASPEED

Graphics Controller Model

AST2600 BMC

Network & Communication

Ethernet Technology

1000BASE-T (1GbE)

I/O Expansions

PCI Express

2x PCI-E 5.0 x16 slots (Low-Profile)
1x PCI-E 3.0 x16 slot (Low-Profile)
1x PCI-E 5.0 x16 OCP3.0 slot (Supports NCSI function)
2x PCI-E 3.0 x2 M.2 slots (Up to 2280)

Drive Bays

Hot-swap

12x 2.5" NVMe Hotswap drive bays

Interfaces/Ports

Total Number of USB Ports

Number of USB 3.0 Ports

3 (1x front, 2x rear)

Number of USB 2.0 Ports

1 (front)

Number of NVMe Interfaces

Number of M.2 slots

LAN

2x RJ45 1000BASE-T (1GbE) Port
1x RJ45 Dedicated Management Port

Onboard Video

1x VGA Connector

Serial/COM

1x COM RJ45 Port

Power Description

Number of Power Supplies

Maximum Power Supply Wattage

1300 W

Certification

80 Plus Platinum

Physical Characteristics

Color

Black

Form Factor

Rack-mountable

Rack Height

Height

1.7"

Width

17.2"

Depth

30.3"
