SabreEDGE 1U 16-Bay E3.S Storage Server - ETS-10752423

Please log in to add an item to your wishlist. MPN: ETS-10752423

SabreEDGE 1U 16-Bay E3.S Storage Server - ETS-10752423

Highlights

Overview

Specifications

The SabreEDGE ETS-10752423 is based on the AMD EPYC 9005/9004 Series processor. It features sixteen E3.S NVMe hot-swap drive bays and support for one PCI-E 5.0 x16 Double-Wide card.

Specifications

Processor & Chipset

Number of Processors Supported

Processor Socket

Socket SP5 LGA-6096

Processor Type

EPYC

Processor Supported

9005-Series
9004-Series

Thermal Design Power (TDP)

500W

Memory

Memory Technology

DDR5 SDRAM

Memory Standard

DDR5-4800
DDR5-5200
DDR5-6400

Number of Total Memory Slots

Controllers

NVMe

16x E3.S PCIe Gen5 NVMe via CPU
2x M.2 PCIe NVMe

Display & Graphics

Graphics Controller Manufacturer

ASPEED

Graphics Controller Model

AST2600

Network & Communication

Ethernet Technology

Via 1x OCP NIC 3.0 PCIe Gen5 x16 Slot

I/O Expansions

PCI Express

1x PCI-E 5.0 x16 FHFL Slot (Supports Double-Wide card)
1x PCI-E 5.0 x16 FHFL Slot
1x PCI-E 5.0 x16 FHHL Slot
1x PCI-E 5.0 x16 OCP3.0 Slot
2x PCI-E 3.0 x2 M.2 slots (2280/22110)

Drive Bays

Hot-swap

16x E3.S NVMe Hot-swap drive bays

Interfaces/Ports

Number of USB 3.2 Gen1 Ports

3 (1x front, 2x rear, Type A)

NVMe Interfaces

16x E3.S
2x M.2

LAN

1x Management LAN Port

Onboard Video

1x Mini DisplayPort

Power Description

Number of Power Supplies

Redundant Power Supplies

Yes (1+1)

Maximum Power Supply Wattage

2700 W

Certification

80 Plus Titanium

Physical Characteristics

Form Factor

Rack-mountable

Rack Height

Height

1.71"

Width

17.24"

Depth

32.09"
