SabreEDGE 2U Server - ES2-10583105

Please log in to add an item to your wishlist. MPN: ES2-10583105

SabreEDGE 2U Server - ES2-10583105

Highlights

Overview

Specifications

The SabreEDGE ES2-10583105 is based on the AMD EPYC 9004/9005 series processor. It offers two 2.5" SATA/NVMe hot-swap drive bays with support for up to two double-wide cards.

Specifications

Processor & Chipset

Number of Processors Supported

Processor Socket

Socket SP5 LGA-6096

Processor Type

EPYC

Processor Supported

9004-Series
9005-Series

Thermal Design Power (TDP)

400W (500W under specific conditions)

Memory

Maximum Memory

3 TB

Memory Technology

DDR5 SDRAM

Memory Standard

DDR5-4800/PC5-38400 (EPYC 9004 Series)
DDR5-6000/PC5-48000 (EPYC 9005 Series)

Number of Total Memory Slots

Controllers

Controller Type

SATA3
NVMe

Display & Graphics

Graphics Controller Manufacturer

ASPEED

Graphics Controller Model

AST2600

Network & Communication

Ethernet Technology

1000BASE-T

I/O Expansions

PCI Express

2x PCI-E 5.0 x16 FHFL slots (Supports Double-Wide cards)
2x PCI-E 5.0 x16 OCP3.0 slots (Supports NCSI function)
1x PCI-E 3.0 x4 M.2 slot (2280/22110)

Drive Bays

Hot-swap

2x 2.5" Rear Hot-swap drive bays
Supports 2x SATA/NVMe hybrid

Interfaces/Ports

USB Ports

2x USB 3.2 Gen1 port (Front, Type A)
2x USB 3.2 Gen1 port (Rear, Type A)

Number of NVMe Interfaces

2x U.2
1x M.2

Number of SATA Interfaces

LAN

1x 1000BASE-T Ports
1x RJ45 Dedicated Management Port

Onboard Video

1x Mini DisplayPort

Trusted Platform Module

1x TPM Header with SPI interface (Optional)

Power Description

Number of Power Supplies

Maximum Power Supply Wattage

2000 W

Certification

80 Plus Titanium

Physical Characteristics

Color

Black

Form Factor

Rack-mountable

Rack Height

Height

3.44"

Width

17.24"

Depth

20.47"
