TYAN B5631G88V2HR-2T-N Thunder HX GA88B5631- 1U Rack Barebone - 4x GPU - LGA-3647

MPN: B5631G88V2HR-2T-N
Highlights
  • Number of Processors Supported: 1
  • Processor Socket: Socket P LGA-3647
  • Maximum Memory: 1.50 TB
  • Memory Standard: DDR4-2666/PC4-21300
Contact sales for pricing
Please log in to add an item to your wishlist.
Need Help? Let's talk about it.
Please log in to add an item to your wishlist.
MPN: B5631G88V2HR-2T-N
Contact sales for pricing

TYAN B5631G88V2HR-2T-N Thunder HX GA88B5631- 1U Rack Barebone - 4x GPU - LGA-3647

Highlights
  • Number of Processors Supported: 1
  • Processor Socket: Socket P LGA-3647
  • Maximum Memory: 1.50 TB
  • Memory Standard: DDR4-2666/PC4-21300
General Information
Manufacturer
Tyan Computer Corp
Manufacturer Part Number
B5631G88V2HR-2T-N
Manufacturer Website Address
http://www.tyan.com
Brand Name
Tyan
Product Line
Thunder HX
Product Model
HX GA88B5631
Product Name
Thunder HX GA88B5631 (B5631G88V2HR-2T-N)
Product Type
Barebone System
Number of GPUs Supported
4
Processor & Chipset
Number of Processors Supported
1
Processor Socket
Socket P LGA-3647
Processor Supported
Xeon
64-bit Processing
Yes
Chipset Manufacturer
Intel
Chipset Model
C621
Memory
Maximum Memory
1.50 TB
Memory Technology
DDR4 SDRAM
Memory Standard
DDR4-2666/PC4-21300
Number of Total Memory Slots
12
Controllers
Controller Type
  • Serial ATA/600
  • 12Gb/s SAS
RAID Supported
Yes
Display & Graphics
Graphics Controller Manufacturer
ASPEED
Graphics Controller Model
AST2500
Network & Communication
Ethernet Technology
10 Gigabit Ethernet
I/O Expansions
Number of Total Expansion Bays
2
Number of Internal 2.5" Bays
2
Number of Total Expansion Slots
5
Number of PCI Express x16 Slots
5
Interfaces/Ports
Total Number of USB Ports
4
Number of USB 3.0 Ports
4
Number of SATA Interfaces
4
Software
Operating System Supported
  • Windows Server 2012 R2 x64
  • Red Hat Enterprise Linux 6.4 x64
  • Red Hat Enterprise Linux 6.5 x64
  • Red Hat Enterprise linux 7.3 x64
  • Red Hat Enterprise linux 7.4 x64
  • CentOS 7.3 x64
  • CentOS 7.4 x64
  • Ubuntu 16.04 LTS x64
  • Ubuntu 17.04 x64
  • SuSE Linux Enterprise Server 11 x64
  • SuSE Linux Enterprise Server 12 x64
Power Description
Input Voltage
  • 120 V AC
  • 230 V AC
Number of Power Supplies Installed
2
Maximum Power Supply Wattage
1600 W
Physical Characteristics
Form Factor
Rack-mountable
Rack Height
1U
Height
1.7"
Width
17.2"
Depth
34.5"
Weight (Approximate)
29.76 lb
Miscellaneous
Package Contents
  • Thunder HX GA88B5631 (B5631G88V2HR-2T-N)
  • 1 x Quick Installation Guide
  • 1 x TYAN installation CD
Environmentally Friendly
Yes
Environmental Certification
RoHS-6
Warranty
Limited Warranty
3 Year
