AMD 100-703205 TV Wonder Elite TV Tuner

MPN # 100-703205 UPC # 727419412216
Condition: New
Product highlights:
  • Product Type: TV Tuner
  • Maximum Resolution: 1024 x 768
  • Platform Supported: PC
  • Host Interface: PCI
Contact sales for pricing

Need Help?

let's talk about it.

Turn your PC into a High-End Home Theater
Get a high-end home theater system with the flexibility and advanced features only a PC can offer with ATI's TV Wonder Elite. This revolutionary product adds consumer electronics quality video to your PC for a fraction of the cost of expensive separate components. Featuring high quality TV and stereo FM radio, TV Wonder Elite delivers full hardware MPEG-2 compression, a 3D comb filter, and advanced noise reduction for advanced Personal Video Recorder capabilities.

General Information
Advanced Micro Devices, Inc
Manufacturer Part Number
Manufacturer Website Address
Brand Name
Product Line
TV Wonder
Product Model
Product Name
TV Wonder Elite TV Tuner
Product Type
TV Tuner
Technical Information
  • FM Tuning
  • TV Tuning
  • Video Capturing
  • Video System
    Maximum Resolution
    1024 x 768
    Platform Supported
    Host Interface
    Audio Line In
    Software Included
    • CyberLink Power Cinema
    Package Contents
    • TV Wonder Elite PCI card
    • REMOTE Wonder PLUS wireless remote control with USB receiver
    • ATI input connection block
    • FM radio antenna
    • 6' S-Video cable
    • 6' Composite cable
    • 2 AAA batteries
    • TV Wonder Elite PCI User Guide
    • TV Wonder Elite PCI Installation CD
    Additional Information
    • 12-bit video decoder
    • 2D comb filter
    • 3D comb filter
    • Automatic gain control
    • MPEG-2 encoding
    • Digital audio
    • Noise reduction
    System Requirements
    • Intel Pentium 4 or Celeron, AMD Athlon or Sempron (or compatible)
    • 128 MB of system memory; 256 MB or more is recommended for best performance
    • Sound Card and speakers
    • Motherboard with available PCI slot
    • Cable TV signal or amplified antenna
    • Installation software requires CD-ROM drive
    • TV Wonder Elite is compatible with all high quality graphics sub-systems supporting DirectX overlay, including products from the following manufacturers:
    • ATI
    • NVIDIA
    • An ATI RADEON 9600 or newer graphics card is recommended for optimal display output quality
    • Windows XP (Professional or Home, Service Pack 2)
    • Windows XP Media Center Edition 2005
    Certifications & Standards
    • FCC Class B certified
    • CE
    • CISPR 22 Class B
    • cUL
    • EN 60950
    • IEC 60950
    • EN55024
    • UL 60950 Third Edition
    • CSA 22.2 No. 60950
    • EN55022 Class B
    • ICES-003 Class B
    • EN 61000-4-4
    • EN 61000-4-2
    • EN 61000-4-3
    • EN 61000-4-6
    • EN 61000-4-5
    Limited Warranty
    3 Year
